9.5.6 RAD-DOR4-IFS process data
I/O module Module type
ID
Number of
registers
Address area Function
code
RAD-DOR4-IFS 10
hex
02
hex
40xx0 ... 40xx1
1
1
xx = I/O-MAP address set using the thumbwheel
fc 03, 16
40xx1 Digital outputs
15 14 13 12 11 10 09 08 07 06 05 04 03 02 01 00
DO
4
DO
3
DO
2
DO
1
Terminal point
6.x 5.x 2.x 1.x
40xx2 ... 40xx9 Reserved
