9.5.4 RAD-DI4-IFS process data
9.5.5 RAD-DI8-IFS process data
I/O module Module type
ID
Number of
registers
Address area Function
code
RAD-DI4-IFS 01
hex
02
hex
30xx0 ... 30xx1
1
1
xx = I/O-MAP address set using the thumbwheel
fc 04
30xx1 Digital inputs
15 14 13 12 11 10 09 08 07 06 05 04 03 02 01 00
DI4 DI3 DI2 DI1
Terminal point
6.x 5.x 2.x 1.x
30xx2 ... 30xx9 Reserved
I/O module Module type
ID
Number of
registers
Address area Function
code
RAD-DI8-IFS
02
hex
Static mode
02
hex
Static inputs
30xx0 ... 30xx1
1
1
xx = I/O-MAP address set using the thumbwheel
fc 04
40
hex
Pulse counter
mode
06
hex
Pulse inputs
30xx0 ... 30xx5
1
fc 04
40
hex
Pulse counter
mode
02
hex
Reset counter
states
40xx0 ... 40xx1
1
fc 03, 16
