Phoenix Contact RAD-900-DAIO6

Addressing I/O extension modules and RAD-900-DAIO6 with Modbus RTU
3827_en_B PHOENIX CONTACT 101/138
9.5.1 RAD-AI4-IFS process data
I/O module Module type
ID
Number of
registers
Address area Function
code
RAD-AI4-IFS 20
hex
06
hex
30xx0 ... 30xx5
1
1
xx = I/O-MAP address set using the thumbwheel
fc 04
30xx1 Reserved
30xx2 Analog input 1 (terminal point 2.x)
15 14 13 12 11 10 09 08 07 06 05 04 03 02 01 00
AI1
30xx3 Analog input 2 (terminal point 3.x)
15 14 13 12 11 10 09 08 07 06 05 04 03 02 01 00
AI2
30xx4 Analog input 3 (terminal point 4.x)
15 14 13 12 11 10 09 08 07 06 05 04 03 02 01 00
AI3
30xx5 Analog input 4 (terminal point 5.x)
15 14 13 12 11 10 09 08 07 06 05 04 03 02 01 00
AI4
30xx6 ... 30xx9 Reserved
