120/138
PHOENIX CONTACT 3827_en_B
Table 10-3 Detecting and removing errors: I/O extension module
LED,
I/O module
Current state and possible
cause
Solution
PWR off No power supply. Mains
probably switched off.
Switch the mains on, restore the power supply.
Ensure the power select switch is in the correct position for the type
of power (RAD-900-DAIO6 only)
Check the fuse (RAD-900-DAIO6)
DAT off No communication between
wireless module and I/O
extension module. Wireless
module possibly in “Serial data”
operating mode.
Check whether the I/O extension module is properly snapped onto
the DIN rail connector and whether it is connected to the wireless
module.
Check the operating mode of the wireless module using the
PSI-CONF software. The wireless module must either be in “I/O
data” or “PLC/Modbus RTU” mode (see Section 5.6, “Configuration
via PSI-CONF software”).
Reset the wireless module to the default settings (I/O data mode,
see “Resetting to the default settings” on page 67), if required.
ERR on Critical internal error
Example: Technical defect
Please contact Phoenix Contact technical support.
ERR
flashing
slowly
(1.4 Hz)
I/O-MAP address changed
Example: The white
thumbwheel setting has
accidentally been modified and
the modification has not yet
been confirmed via the SET
button.
Check the IO-MAP address setting on the white thumbwheel of the
I/O extension module.
If necessary, set the correct I/O-MAP address and press the SET
button on the wireless module.
In I/O data mode
ERR
flashing fast
(2.8 Hz)
Missing input module
Example: An output module
does not have the
corresponding input module
with the same I/O-MAP address.
Check whether an input module with the same I/O-MAP address has
been assigned to each output module.
Set the I/O-MAP address (01 ... 99) using the white thumbwheel on
the extension module. The input module must be provided with the
same I/O-MAP address as the assigned output module at the other
wireless station.
No bus communication, no
wireless connection present
See measures for the wireless module, page 117
