Table 5-3 Assignment of input and output modules
5.7.2 Setting the address of the extension modules via the
thumbwheel
For an I/O-to-I/O transmission of signals, assign a corresponding output module to the input
module. Set the I/O-MAP address (01 ... 99) using the white thumbwheel on the I/O
extension module.
Addressing extension modules
• Use the thumbwheel to set the address.
• Press the SET button on the front of the wireless module to read the current
configuration.
The following settings can be made using the white thumbwheel:
The following conditions must be met:
– Assign a maximum of 1 ... 99 addresses to the extension modules in the entire wireless
network.
Input module Output module
2901537 RAD-AI4-IFS 2901538 RAD-AO4-IFS
2904035 RAD-PT100-4-IFS 2901538 RAD-AO4-IFS
2901535 RAD-DI4-IFS 2901536 RAD-DOR4-IFS
2901539 RAD-DI8-IFS 2902811 RAD-DO8-IFS
2901533 RAD-DAIO6-IFS 2901533 RAD-DAIO6-IFS
Thumbwheel
setting
Description
01 ... 99 I/O-MAP address
00 Delivery state
**, 1* ... 9* Setting not permitted
*1 ... *9 Interface System slave address, for use with other Interface System
(IFS) master devices
