9.5.2 RAD-PT100-4-IFS process data
I/O module Module type
ID
Number of
registers
Address area Function
code
RAD-PT100-4-IFS 21
hex
06
hex
30xx0 ... 30xx5
1
1
xx = I/O-MAP address set using the thumbwheel
fc 04
30xx1 Reserved
30xx2 Pt 100 input 1 (terminal point 2.x)
15 14 13 12 11 10 09 08 07 06 05 04 03 02 01 00
T1
30xx3 Pt 100 input 2 (terminal point 3.x)
15 14 13 12 11 10 09 08 07 06 05 04 03 02 01 00
T2
30xx4 Pt 100 input 3 (terminal point 4.x)
15 14 13 12 11 10 09 08 07 06 05 04 03 02 01 00
T3
30xx5 Pt 100 input 4 (terminal point 5.x)
15 14 13 12 11 10 09 08 07 06 05 04 03 02 01 00
T4
30xx6 ... 30xx9 Reserved
