5.1.2 Firmware update
The firmware can be updated using the PSI-CONF software. The device is reset to the
default settings after a firmware update.
1. Select “Wireless, RAD-900-IFS” on the “Device Selection” page.
2. Select “Update firmware”.
5.2 Operating mode of the wireless module
The Radioline wireless system offers four different options for signal and data transmission:
If the wireless system is operated in an environment where other networks are also present
(e.g., additional Radioline networks in the 900 MHz band), then a configuration memory can
be used (see “Configuration via CONFSTICK” on page 71). For configuring extended
settings of the wireless modules, it is also possible to use the PSI-CONF software (from
page 74 onwards).
Download the latest firmware free of charge at
phoenixcontact.net/products.
Operating mode Configuration
I/O data mode Default setting, configuration only possible via
thumbwheel
Serial data mode
Configuration via PSI-CONF softwarePLC/Modbus RTU mode
PLC/Modbus RTU dual mode
Only one operating mode can be selected. It is not possible to simultaneously transmit I/O
signals and serial data.
