RAD-900-...
66/138
PHOENIX CONTACT 3827_en_B
4.2.5 Connecting the antenna
The wireless module has an N-type antenna socket for an external antenna. Although a
0 dB omni-directional antenna is included with the wireless module, it may be replaced with
a coaxial cable and high-gain antenna.
If the antenna is removed and re-installed or a cable is attached for a remote antenna,
torque the antenna or cable connector between 0.7 and 1.1 Nm.
Install the antenna outside the control cabinet or building.
Observe the installation instructions of the antenna and the “Installation and operation” on
page 6.
Observe the maximum permissible emitted transmission power of 36 dBm. The
transmission power can be calculated as:
device transmission power + antenna gain - cable attenuation
Reduce the device transmission power, if necessary.
