Phoenix Contact RAD-900-DAIO6

Addressing I/O extension modules and RAD-900-DAIO6 with Modbus RTU
3827_en_B PHOENIX CONTACT 103/138
9.5.3 RAD-AO4-IFS process data
I/O module Module type
ID
Number of
registers
Address area Function
code
RAD-AO4-IFS 30
hex
06
hex
40xx0 ... 40xx5
1
1
xx = I/O-MAP address set using the thumbwheel
fc 03, 16
40xx1 Reserved
40xx2 Analog output 1 (terminal point 2.x)
15 14 13 12 11 10 09 08 07 06 05 04 03 02 01 00
AO1
40xx3 Analog output 2 (terminal point 3.x)
15 14 13 12 11 10 09 08 07 06 05 04 03 02 01 00
AO2
40xx4 Analog output 3 (terminal point 4.x)
15 14 13 12 11 10 09 08 07 06 05 04 03 02 01 00
AO3
40xx5 Analog output 4 (terminal point 5.x)
15 14 13 12 11 10 09 08 07 06 05 04 03 02 01 00
AO4
40xx6 ... 40xx9 Reserved
