3.5.7 Process data in PLC/Modbus RTU mode
The process image of the I/O extension module consists of eight data words. For additional
information, please refer to Section 3.5, “RAD-DI8-IFS - digital extension module with eight
inputs”.
I/O module Module type
ID
Number of
registers
Address area Function code
RAD-DI8-IFS
02
hex
Static mode
02
hex
Static inputs
30xx0 ... 30xx1 fc 04
40
hex
Pulse counter
mode
06
hex
Pulse inputs
30xx0 ... 30xx5 fc 04
40
hex
Pulse counter
mode
02
hex
Reset counter
states
40xx0 ... 40xx1 fc 03, 16
