9.6 Error codes and formats for analog input and
output values
The measured value is represented in bits 0 ... 15. Values higher than 8000
hex
indicate an
error.
Analog RAD-AI4-IFS inputs
Table 9-6 Representation of analog RAD-AI4-IFS values
Analog RAD-AO4-IFS outputs
Table 9-7 Representation of analog RAD-AO4-IFS values
Analog RAD-DAIO6-IFS and RAD-900-DAIO6 inputs and outputs
Table 9-8 Representation of analog RAD-DAIO6-IFS values
Data word
hex dec/error code 0 mA ... 20 mA 4 mA ... 20 mA
0000 0 0 mA -
1770 6000 4 mA 4 mA
7530 30000 20 mA 20 mA
7F00 32512 21.67 mA 21.67 mA
8001 Overrange >21.67 mA >21.67 mA
8002 Open circuit - <3.2 mA
8080 Underrange < 0 mA -
Data word
hex dec/error code 0 mA ... 20 mA 0 V ... 10 V
0000 0 0 mA 0 V
7530 30000 20 mA 10 V
7F00 32512 21.67 mA 10.84 V
Data word
hex dec/error code 0 ... 20 mA 4 ... 20 mA 0 V ... 10 V
0000 0 0 mA - 0 V
1770 6000 4 mA 4 mA 2 V
7530 30000 20 mA 20 mA 10 V
7F00 32512 21.67 mA 21.67 mA 10.84 V
8001 Overrange >21.67 mA >21.67 mA -
8002 Open circuit - <3.2 mA -
8080 Underrange <0 mA - -
