Phoenix Contact RAD-900-DAIO6

Addressing I/O extension modules and RAD-900-DAIO6 with Modbus RTU
3827_en_B PHOENIX CONTACT 105/138
30xx1 Digital inputs DI1 ... DI8 (static mode)
15 14 13 12 11 10 09 08 07 06 05 04 03 02 01 00
DI8 DI7 DI6 DI5 DI4 DI3 DI2 DI1
Terminal point
5.x 5.x 4.x 4.x 3.x 3.x 2.x 2.x
30xx2 DI1: 32-bit pulse input, pulse counter mode
(terminal point 2.x)
15 14 13 12 11 10 09 08 07 06 05 04 03 02 01 00
Counter state DI1, low word
30xx3 DI1: 32-bit pulse input, pulse counter mode
(terminal point 2.x)
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
Counter state DI1, high word
30xx4 DI7: 32-bit pulse input, pulse counter mode
(terminal point 5.x)
15 14 13 12 11 10 09 08 07 06 05 04 03 02 01 00
Counter state DI7, low word
30xx5 DI7: 32-bit pulse input, pulse counter mode
(terminal point 5.x)
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
Counter state DI7, high word
30xx6 ... 30xx9 Reserved
40xx1 Reset of counter states DI1/DI7
15 14 13 12 11 10 09 08 07 06 05 04 03 02 01 00
X
1
1
Bit 1 = 1: counter state DI7 reset to 0
X
2
2
Bit 0 = 1: counter state DI1 reset to 0
40xx2 ... 40xx9 Reserved
