I/O input data, address area 30010 ... 30999
Modbus function code 04
I/O output data, address area 40010 ... 40999
Modbus function code 03, 16
RAD-DO8-IFS RAD-DO8-IFS
I/O-
MAP
High byte 15 ... 8 Low byte 7 ... 0
I/O-
MAP
High byte 15 ... 8 Low byte 7 ... 0
30 xx 0
Currentness of data Module type ID
40 xx 0
Currentness of data Module type ID
X X X X X X X X X X X X X X X X X X
30 xx 1
Short-circuit detection
Bit 0: DO 1 ... 4, Bit 1: 5 ... 8
40 xx 1
DO
9 8 7 6 5 4 3 2 1
X X X X X X X X X X X
30xx2 ... 30xx9 reserved 40xx2 ... 40xx9 reserved
RAD-AI4-IFS RAD-AO4-IFS
I/O-
MAP
High byte 15 ... 8 Low byte 7 ... 0
I/O-
MAP
High byte 15 ... 8 Low byte 7 ... 0
30 xx 0
Currentness of data Module type ID
40 xx 0
Currentness of data Module type ID
X X X X X X X X X X X X X X X X X X
30 xx 1 Reserved 40 xx 1 Reserved
30 xx 2
AI1
40 xx 2
AO1
X X X X X X X X X X X X X X X X X X X X X X X X X X X X X X X X
30 xx 3
AI2
40 xx 3
AO2
X X X X X X X X X X X X X X X X X X X X X X X X X X X X X X X X
30 xx 4
AI3
40 xx 4
AO3
X X X X X X X X X X X X X X X X X X X X X X X X X X X X X X X X
30 xx 5
AI4
40 xx 5
AO4
X X X X X X X X X X X X X X X X X X X X X X X X X X X X X X X X
30xx6 ... 30xx9 reserved 40xx6 ... 40xx9 reserved
