RAD-900-...
76/138
PHOENIX CONTACT 3827_en_B
Table 5-2 Data transmission speed of the wireless interface
Figure 5-7 PSI-CONF software: Wizard, Step 3
Figure 5-8 PSI-CONF software: Setting the data transmission speed
Data
transmission
speed
Typical receiver
sensitivity
Typical link
budget
Potential distance with line
of sight and a system
reserve of 12 dB
500 kbps -95 dBm -125 dBm 12 km
250 kbps -102 dBm -132 dBm 25 km
125 kbps -105 dBm -135 dBm 35 km (default setting)
16 kbps -112 dBm -142 dBm 80 km
