LIFEPAK 500 automated external defibrillator Replacement Procedures
11-75
Replacing Lower Enclosure Perimeter Seal
Preparation Before replacing the Lower Enclosure Perimeter Seal, you must first follow these
procedures:
■ Removing Top Cover
WARNING!
Shock hazard. The Energy Storage Capacitor carries high voltage.
Remove the battery and discharge the capacitor before handling. See:
■ Discharging Energy Storage Capacitor
To remove the Lower Enclosure Perimeter Seal:
1. Grasp one end of the perimeter seal and gently pull the seal away from the
groove along the edge of the lower enclosure.
2. Install the replacement perimeter seal by gently pushing the seal into the
groove along the edge of the lower enclosure. Be careful to avoid stretching
the perimeter seal.
3. Align the ends of the perimeter seal as shown in the detail on the left.
After you have installed the new perimeter seal, jump to the Reassembling
Case procedure.
Perimeter Seal
