LIFEPAK 500 automated external defibrillator Troubleshooting
8-17
Fault Code Table Page 14 of 20
Code Fault Description
Corrective
Action
Code
6103 dsp_hostcomm_tx_length_err 10
6200 dsp_acq_fault_minor 10
6201 acq_a2d_channel_error 2
6202 acq_a2d_no_avail_buff 10
6203 acq_ssi_rx_error 2
6204 acq_not_used 10
6205 acq_isr_timing_error 10
6300 dsp_defib_fault_minor 10
6301 defib_cap_voltage_sample_missed 10
6302 defib_cap_voltage_acq_error 10
6303 dsp_energy_cal_factor_unknown 6, 2
6500 dsp_boot_fault_minor 10
6600 dsp_a2d_chan_fault_minor 2
6601 dsp_fault_last 10
8000 major_fault 10
9100 boot_fault_major 10
9101 boot_ram_access_fail 2
9102 boot_dsp_not_initializing 10, 2
Corrective Action Code Key
Code Description
1 Try to reload the software
2 Replace the Main PCB
3 Replace the Connector
4 Replace the Energy Storage Capacitor
5 Replace the Inductor
6 Recalibrate/Restore Setup, Complete PIP,
Return to service if fault codes do not recur
7 Check the Wires
8 Check the Battery
9 Replace the Time-of-Day Clock Battery
10 Clear Faults, Complete PIP, Return to service
if fault codes do not recur
11 Replace the Biphasic PCB
