LIFEPAK 500 automated external defibrillator Troubleshooting
8-16
Fault Code Table Page 13 of 20
Code Fault Description
Corrective
Action
Code
5f0a bte_failed_htest_short1 11
5f0b bte_failed_htest_short2 11
5f0c bte_failed_htest_short3 11
5f0d bte_failed_htest_open1 11
5f0e bte_failed_htest_open2 11
5f0f bte_failed_htest_unscaled 11
5f10 bte_failed_htest_scaled 11
5f11 bte_failed_htest_vcap_high 10, 11, 2
5f12 bte_failed_htest-vcap_low 10, 11, 2
5f13 bte_failed_vref_high 11
5f14 bte_failed_vref_low 11
5f15 bte_failed_htest_agc 11
5f16 bte_failed_dump 11
5f17 bte_failed_htest_unknown 11
5f18 bte_faultline_error 10, 11
6100 dsp_hostcomm_fault_minor 10
6101 dsp_hostcomm_pkt_no_ack 10
6102 dsp_hostcomm_bad_packets_rx 10
Corrective Action Code Key
Code Description
1 Try to reload the software
2 Replace the Main PCB
3 Replace the Connector
4 Replace the Energy Storage Capacitor
5 Replace the Inductor
6 Recalibrate/Restore Setup, Complete PIP,
Return to service if fault codes do not recur
7 Check the Wires
8 Check the Battery
9 Replace the Time-of-Day Clock Battery
10 Clear Faults, Complete PIP, Return to service
if fault codes do not recur
11 Replace the Biphasic PCB
