Planet WGSW-20160HP - Logon to the Console; Configuring IP Address

Command Guide
-26-
2.2 Logon to the Console
Once the terminal is connected to the device, power on the Industrial Managed Switch, and the terminal will display “running
testing procedures”. Then, the following message asks to log-in user name and password. The factory default user name and
password are shown as follows and the login screen in Figure 3-1 appears.
Username: admin
Password: admin
Figure 3-1: Industrial Managed Switch Console Login Screen
The user can now enter commands to manage the Industrial Managed Switch. For a detailed description of the commands,
please refer to the following chapters.
1. For security reason, please change and memorize the new password after this first setup.
2. Only accept command in lowercase letter under console interface.
2.3 Configuring IP Address
The Industrial Managed Switch is shipped with default IP address shown below.
IP Address: 192.168.0.100
Subnet Mask: 255.255.255.0
