Planet WGSW-20160HP - Evc Policer

Command Guide
-88-
disable No tag added when forwarding to UNI
enable Add tag when forwarding to UNI
pcp Setup added tag PCP
<AddPcp : 0-7> Added tag PCP
preserve Setup tag PCP/DEI preservation
vid Setup added tag VLAN ID
<AddVid : vlan_id> Added tag VLAN ID
match Setup outer tag match properties
policer Policer (ingress bandwidth profile)
<PolicerId : 1-2048> Policer ID
discard Map to policer discarding all frames
evc Use policer setup for EVC
none Map to policer allowing all frames
policy Setup ACL policy
<PolicyNo : 0-255> ACL policy
pop Setup tag popping
<Pop : 0-2> Number of tags popped
Default:
N/A
Usage Guide:
To update EVC Control Entry for specific ECE profile.
Example 1:
To update “direction nni-to-uni” for ECE profile 1.
Switch# configure terminal
Switch (config)# evc ece 1 direction nni-to-uni
4.2.54 evc policer
Command:
evc policer <PolicerId : 1-2048> [enable | disable] cbs <Cbs : 0-100000> cir <Cir :
0-10000000> ebs <Ebs : 0-100000> eir <Eir : 0-10000000> mode [aware | blind |
coupled] rate-type [data | line] type [mef | single]
<PolicerId : 1-2048> Policer ID
cbs Setup CBS
<Cbs : 0-100000> Committed Burst Size [bytes]
