Planet WGSW-20160HP - Evc Ece

Command Guide
-83-
Switch# configure terminal
Switch (config)# evc 1 vid 2 interface GigabitEthernet 1/1-2 ivid 3 learning disable
policer 4
4.2.52 evc ece
Command:
evc ece <EceId : 1-4096> direction {both | nni-to-uni | uni-to-nni} evc {
<EvcId :
1-4096> | none} frame-type {any | ipv4 | ipv6} inner-tag { add {dei <AddDei : 0-1> |
pcp <AddPcp : 0-7> | preserve | type [c-tag | none | s-custom-tag | s-tag] | vid
<AddVid : vlan_id>}, match {dei [<MatchDei : 0-1> | any]| pcp [<MatchPcp : pcp> |
any] | type [any | c-tagged | s-tagged | tagged | untagged] | vid [<Vid : 0-4095> |
any]} } interface [* | 10GigabitEthernet | GigabitEthernet] <PORT_ID> next [<EceId :
1-4096> | last] outer-tag { add {dei <AddDei : 0-1> | pcp <AddPcp : 0-7> | preserve |
type [c-tag | none | s-custom-tag | s-tag] | vid <AddVid : vlan_id>}, match {dei
[<MatchDei : 0-1> | any]| pcp [<MatchPcp : pcp> | any] | mode [disable | enable] | vid
[<Vid : 0-4095> | any] } policer {<PolicerId : 1-2048> | discard | evc | none} policy
<PolicyNo : 0-255> pop <Pop : 0-2>
<EceId : 1-4096> ECE identifier
direction Setup ECE direction
both Bidirectional traffic flow
nni-to-uni NNI-to-UNI traffic flow
uni-to-nni UNI-to-NNI traffic flow
evc EVC mapping
<EvcId : 1-4096> EVC identifier
none Map to no EVC ID
frame-type Setup matched frame type
any Match any frame type
ipv4 Match IPv4 frames
ipv6 Match IPv6 frames
inner-tag Setup inner tag options
add Setup inner tag add properties.
dei Setup added tag DEI
<AddDei : 0-1> Added tag DEI
pcp Setup added tag PCP
