Planet WGSW-20160HP - Show Voice Vlan

Command Guide
-428-
at Ether Type is AppleTalk
ip Ether Type is IP
ipx Ether Type is IPX
llc LLC-based VLAN status
<dsap> DSAP (Range: 0x00 - 0xFF)
<ssap> SSAP (Range: 0x00 - 0xFF)
snap SNAP-based VLAN status
<oui> SNAP OUI (Range 0x000000 - 0XFFFFFF)
rfc-1042 SNAP OUI is rfc-1042
snap-8021h SNAP OUI is 8021h
<pid> PID (Range: 0x0 - 0xFFFF)
Default:
N/A
Usage Guide:
To display the Protocol-based VLAN information.
Example:
To display the Protocol-based VLAN information.
Switch # show vlan protocol
Protocol Type Protocol (Value) Group ID
------------- ------------------------ --------
LLC_SNAP OUI-00:e0:2b; PID:0x1 q
Switch 1
---------
Group ID VID Ports
---------------- ---- -----
q 2 GigabitEthernet 1/1
4.21.108 show voice vlan
Command:
show voice vlan [ oui <oui> | interface ( <port_type> [ <port_list> ] ) ]
show Show running system information
voice Voice appliance attributes
vlan Vlan for voice traffic
interface Select an interface to configure
