Polaris RANGER EV 2015 User Manual

5.16
9926595 R01 - 2015-2016 RANGER EV Service Manual
© Copyright Polaris Industries Inc.
CENTRALIZED HILLIARD EXPLODED VIEW
REF# DESCRIPTION
QTY
REF# DESCRIPTION
QTY
1
Flanged Bolt
11 20
Bushing
1
2
Dowel Pin
1 21 Coil 1
3
Bearing
2 22 Cover Plate 1
4
Garlock Bearing
1 23 Gearcase 1
5
Thrust Bearing
1 24 Grommet 1
6 Oil Seal 2 25
H-Clip Spring
14
7
Internal Ring
1 26
Input Cover
1
8
Bushing
1 27
Magnetic Drain Plug
1
9
Clutch Housing / Ring Gear
1 28 Oil Seal 1
10 Thrust Plate 1 29 Pinion Gear 1
11
Roll Cage Asm (Includes H-Springs)
1 30
Fill Plug Assembly
1
12 Bolt 1 31
Bearing Roller
14
13
Output Hub (Female)
1 32
Bearing Cage
1
14
Output Hub (Male)
1 33
Spacer, Gear
1
15
Thrust Button Assembly
1 34
Vent Tube Fitting
1
16 Armature Plate
1 35
External Ring
1
17
O-Ring / Seal
1 36
Torsion Return Spring
1
18
O-Ring / Seal
1 37
Shim, Gear
1
19
Bearing
1
AWD DIAGNOSIS
Symptom: No AWD engagement or intermittent
function.
1. Open the hood and locate the connector (A) for AWD
engagement coil. Separate the connector.
FINAL DRIVE
