9926595 R01 - 2015-2016 RANGER EV Service Manual
© Copyright Polaris Industries Inc.
SPECIFICATIONS
TORQUE SPECIFICATIONS
ITEM
TORQUE
Terminal Block Nuts
(3 motor cables to motor)
11 ft-lb (15 Nm)
Terminal Cover Screw
31 in-lb (4 Nm)
Motor Case Bolts
8 ft-lb (11 Nm)
Motor Mounting Bolts (M6) 8 ft-lb (11 Nm)
Motor Mounting Bolt (M8) 17 ft-lb (23 Nm)
Motor Support Bracket to Motor 8 ft-lb (11 Nm)
Motor Support Bracket to Frame 17 ft-lb (23 Nm)
Speed Sensor Screw 62 in-lb (7 Nm)
MOTOR SERVICE DATA
DRIVE MOTOR COMPONENT SPECIFICATION
STATOR
Winding Resistance
0.1-0.2 Ω +/- 20%
Winding Resistance to Motor Case Infinite (O.L.)
TEMPERATURE
SENSOR
(Thermistor)
Sensor Resistance
(Black Wire to White Wire in the white
harness)
580 W (.580 K +/- 20% @ 68° F (20° C)
TEMPERATURE
SENSOR
(Thermistor)
Sensor Resistance
(Black Wire or White Wire to Motor Case
Infinite (O.L.)
DRIVE MOTOR
To Next Page
