9926595 R01 - 2015-2016 RANGER EV Service Manual
© Copyright Polaris Industries Inc.
7.19
FRONT CALIPER SERVICE
CALIPER EXPLODED VIEW
CALIPER REMOVAL
1. Elevate and safely support the front of the vehicle.
2. Remove the (4) wheel nuts and the front wheel.
WARNING
Use care when supporting vehicle so that it does not tip
or fall. Severe injury may occur.
3. Clean caliper area before removal.
4. Place a container below the caliper to catch brake
fluid when removing the line. Remove brake line
from caliper.
BRAKE SYSTEM
