8
9926595 R01 - 2015-2016 RANGER EV Service Manual
© Copyright Polaris Industries Inc.
8.13
INDICATOR LAMP REPLACEMENT
1. Remove indicator lamp panel by carefully lifting one
edge with a small screwdriver.
2. Lift tab to disconnect panel from harness.
3. Use the following procedure to remove bulb(s).
• Turn lamp holder 1/4 turn with a small screwdriver.
• Pull bulb assembly out with a needle nose pliers
• Replace with a new bulb
4. Reverse disassembly procedure to reinstall indicator
panel.
NOTE
Disconnect the Main Power Connector (see chapter 1)
before disconnecting any electrical component. The
Main Power Connector is the first to disconnect and the
last to connect when servicing the electrical system.
ELECTRICAL
