9926595 R01 - 2015-2016 RANGER EV Service Manual
© Copyright Polaris Industries Inc.
3.11
4. Inspect rotor for damage.
BEARING REPLACEMENT
BEARING MUST BE REPLACED IF REMOVED
1. Remove internal snap-ring
q
.
2. Support cover as shown. Tap or press bearing from
cover.
3. Clean bearing bore and retaining ring groove.
Remove any burrs.
4. Install a new O-ring and lubricate O-ring and bore
with a light film of grease.
5. Set new bearing in freezer on wax paper or plastic
wrap for 15-30 minutes. When bearing is cool, warm
cover on a thermostatically controlled hot plate to
150° F (65° C). Do not exceed 150° F or bearing may
be damaged.
6. Press bearing past O-ring and into bore by hand (if
possible).
7. If bearing cannot be installed by hand, select a
suitable arbor that will press on the outer race of the
bearing. The bearing should install with minimal
press effort.
8. Install the internal snap-ring. Be sure it is fully seated
in the groove.
DRIVE MOTOR
