8.48. FADERGIM -- Set Gain of Microphone Inputs as a Group
This command sets the fader gains of all the microphone inputs simultaneously. This is different from using a
wildcard, * with the FADERI command because that command sets all the mic and line inputs together,
while the FADERGIM sets only the mic inputs.
This command will generate acknowledgements from each of the mic inputs separately.
This command is an integer command. See
Section 6.2 for more information on this type of command. The
minimum and maximum values for this command are -100 and 20, respectively.
This command is saved to non-volatile memory only as part of a preset. The state of this command will be
restored after power-up only if a preset is saved and that preset is set to be the power-on preset.
Example Description Status Message
B01FADERGIM7
Set fader gain of all mic inputs to 7 dB.
B01FADERI17
B01FADERI27
B01FADERI37
B01FADERI47
B01FADERGIM>3
Increase fader gain on all mic inputs
by 3 dB.
B01FADERI1a
B01FADERI2b
B01FADERI3c
B01FADERI4d ,
where a, b, c, and d are the new values of the
fader gains for each of the mic inputs. If this
command was issued after the example above,
then the status messages would be:
B01FADERI110
B01FADERI210
B01FADERI310
B01FADERI410 .
B01FADERGIM?
Query fader gains on all mic inputs.
B01FADERI1a
B01FADERI2b
B01FADERI3c
B01FADERI4d ,
where a, b, c, and d are the new values of the
fader gains for each of the mic inputs. If this
command was issued after the example above,
then the status messages would be:
B01FADERI110
B01FADERI210
B01FADERI310
B01FADERI410 .
8.49. FADERI -- Set Input Gain Fader
The input channels of the Vortex pass through an analog gain stage before reaching the analog to digital
converter. The gain of this stage is adjustable via a the GAINI command. Once in the digital domain, there
