restored after power-up only if a preset is saved and that preset is set to be the power-on preset.
Example Description Status Message
B01GMUTEO1
Enable global output mute.
B01GMUTEO1
B01GMUTEO0
Disable global output mute.
B01GMUTEO0
B01GMUTEO2
Toggle global output mute.
B01GMUTEOx , where x is 0 or 1 depending on the current
state of the global output mute.
B01GMUTEO?
Query acknowledgement mode.
B01GMUTEOx , where x is 0 or 1 depending on the current
state of the global output mute.
8.68. ID -- Set Device ID
This command sets or queries the Device ID for the Vortex. Typically, the device ID is set from the front
panel of the Vortex, so this command is not normally used. There are restrictions involving having devices
with the same ID linked on EF Bus -- see the Vortex Reference Manual for more details.
This command is an integer command. See
Section 6.2 for more information on this type of command. The
minimum and maximum values for this command are 0 and 7, respectively.
This command is saved to global non-volatile memory and is not part of a preset. Its value is saved each
time it is changed. It will retain its value after power-down. Since this command writes to non-volatile
memory, there will be a delay before an acknowledgment is returned.
Example Description Status Message
B01ID3
Change the device ID from 1 to 3
B03ID3
B01ID?
Query current device ID.
B01ID1
8.69. LABEL -- Set or Query one of the Device Labels
This command sets or queries one of the many labels stored in the device. The LABEL command has the
following syntax:
iLABELx,y
where i is the device type and ID, x is the label specifier, and y is the label text (to set the label) or a ?
character (to query the label). The label specifiers are as follows:
Label Specifier Description
D A label for the device itself.
SG A label for the signal generator.
I1-I4, IA-ID, IT Labels for the input channels.
O1-O4, OA-OD, OL, OT Labels for the output channels.
P, W, X, Y, Z Labels for matrix outputs to EF Bus.
PB0-PB7, WB0-WB7, XB0-XB7, YB0-YB7, ZB0-
ZB7
Labels for inputs from EF Bus to submatrices.
