Polycom Vortex EF2241 User Manual

PM0-PM1, WM0-WM2, XM0-XM2, YM0-YM2,
ZM0-ZM2
Labels for outputs from EF Bus submatrices to main
matrix.
R1, R2 Labels for AEC references.
G0-G3 Labels for logic input groups.
LI1-LI24 Labels for logic input pins
LO1-LO20 Labels for logic output pins
P0-P47 Labels for user presets.
M0-M255 Labels for user macros.
The text of each label can be up to 16 characters long. Labels for presets 0-15 are read-only.
This command is saved to global non-volatile memory and is not part of a preset. Its value is saved each
time it is changed. It will retain its value after power-down. Since this command writes to non-volatile
memory, there will be a delay before an acknowledgment is returned.
Example Description Status Message
B01LABELOB,Zone 2 Speaker
Set label of output B to
"Zone 2 Speaker".
B01LABELOB,Zone 2 Speaker
B01LABELOB,?
Query label for output B
.
B01LABELOB,<string> , where <string>
is the current label assigned to output B .
8.70. LAGC -- Enable or Disable Line Input Automatic Gain
Control
This command sets or queries the status of the Automatic Gain Control (AGC) algorithm on input channels A-
D .
This command was introduced in firmware version 2.5.0.
This command is a channel boolean command. See
Section 6.3 and Section 6.1 for more information on this
type of command.
This command is saved to non-volatile memory only as part of a preset. The state of this command will be
restored after power-up only if a preset is saved and that preset is set to be the power-on preset.
Example Description Status Message
B01LAGCB1
Enable AGC on input channel B.
B01LAGCB1
B01LAGCA0
Disable AGC on input channel A.
B01LAGCA0
B01LAGCC2
Toggle AGC state on input channel C .
B01LAGCCx , where x is 0 or 1 depending on the
current state of the AGC on input channel C .
B01LAGCD?
Query AGC state on input channel D .
B01LAGCDx , where x is 0 or 1 depending on the
current state of the AGC on input channel D .
B01LAGC*1
Enable AGC on input channels A-D.
B01LAGC*1111
B01LAGC*0
Disable AGC on input channels A-D.
B01LAGC*0000
