B01LOM?
Query current logic
output mask.
B01LOMabcdefghijklmnopqrst , where a-t
are each 0 or 1 depending on the current state of
the logic output mask.
8.94. LOP -- Set Polarity for Logic Outputs
This command sets the polarity for the 20 logic input pins. Setting the polarity for a given pin to 1 indicates
that the polarity should be normal (active high). Setting the polarity for a given pin to 0 indicates that the
polarity should be inverted (active low). Active high is considered normal because it would light an LED
connected to an output pin if the output pin was in the active state.
This command affects the operation of the
LOA and LOD commands. If a logic input pin's polarity is reversed,
the operation of these commands is reversed.
By default, the polarity for all pins is set to normal (active high).
This command is saved to global non-volatile memory and is not part of a preset. Its value is saved each
time it is changed. It will retain its value after power-down. Since this command writes to non-volatile
memory, there will be a delay before an acknowledgment is returned.
Example Description Status Message
B01LOP11111111111111110000
Set logic outputs 1-
16 to normal
(active high) and
logic outputs 17-
20 to inverted
(active low).
B01LOP11111111111111110000
B01LOP?
Query current
polarity settings
for logic outputs.
B01LOPabcdefghijklmnopqrst , where a-t
are each 0 or 1 depending on the current state of
the logic output polarity for the corresponding logic
output pin.
8.95. MACROA -- Add Command to Current Macro
This command adds a command to the macro currently in progress. This is used in conjunction with the
MACROS and MACROW commands to create a new macro.
The syntax of this command specifies a macro number, a comma, and then the command to be added to the
macro. The command to be added to the macro can be any valid command except the following:
● any PRESET command
● any MACRO command
● any logic input or output command
If an attempt to assign an invalid command to a macro is made (via
MACROA), then the error condition
ERROR#074 will be generated.
An error will be generated if the specified command is not a valid command. However, an error will not be
