Parameter Documentation Sheet 3
FlexFit – Linkageless Control – Revision 1.0
PREFERRED
UTILITIES MFG CORPORATION
Parameter # Parameter Value Range Default
P3.1.4 Span, Custom Blr Outlet Xmtr 5.0 to 2000.0 25.0
P3.1.5 Dec Pt, Custom Blr Outlet Xmtr xxxxx
P3.1.6 Thermistor Deg C Option Disabled
Firing Rate > Tuning
P3.2.1 Proportional Band, Rate PID 0.05 to 50.00 5.00
P3.2.2 Minutes Per Repeat, Rate PID 0.75 to 10.00 1.25
P3.2.3 Sec/100%, Ramp Rate, Firing Rate 35 to 120 45
P3.2.4 Rate Max SP 0.5 to 2000.0 240.0
P3.2.5 Rate Min SP -700.0 to 1900.0 0.0
Firing Rate > 24 Hour Recycle
P3.3.1 Scanner Check 24hr Recycle Option Disabled
P3.3.2 Scanner Check Time of Day, xx:00 0 to 23 9
Firing Rate > Local/Remote Mode
P3.4.1 CFH Local Mode Not Used
P3.4.2 CFH Start Deviation -50.0 to 500.0 5.0
P3.4.3 CFH Stop Deviation 0.1 to 500.0 10.0
P3.4.4 Enable Remote Mode Disabled
P3.4.5 CFH Remote Mode Terminal 17
P3.4.6 Remote Modulation 4-20 mA FR
P3.4.7 Remote Fault Response Local
P3.4.8 Remote Rate Cutback SP 0.5 to 2000.0 2000.0
P3.4.9 Remote SP Span 0.0 to 2000.0 200.0
P3.4.10 Remote SP Zero 0.0 to 2000.0 0.0
Firing Rate > LFH-DHW-Warm Standby
P3.5.1 T27 Options Disable
P3.5.2 DHW, Rate PID Override SP 0.0 to 2000.0 180.0
P3.5.3 Low Fire Hold, Override Seconds 1 to 1800 300
Firing Rate > Cold Start Warmup
P3.6.1 Cold Start Warmup Option Disabled
P3.6.2 Activate SP, Cold Start 0.1 to 1800.0 40.0
P3.6.3 Deactivate SP, Cold Start 0.1 to 1800.0 100.0
P3.6.4 Setpoint Step, Cold Start 0.1 to 200.0 10.0
P3.6.5 Firing Rate Step, Cold Start 2.0 to 30.0 10.0
P3.6.6 Firing Step Override Minutes, Cold Start 1 to 120 20
Firing Rate > Advanced
P3.7.1 Operator High Fire Limiter Option Disabled
P3.7.3 +/- Avoid Gap, Firing Rate 0.2 to 5.0 1.5
Draft Control > Basic
P4.1.1 Draft Control Option Disabled
P4.1.2 Outlet Damper Purge Position 30.00 to 200.00 80.00
P4.1.3 Draft @ 4 mA, Xmtr Cal -25.000 to 25.000 1.000
