MAX™ Operator Manual
©
Original Printed In English
This section describes and lists Permissive and Special Conditions. In general terms, a Permissive is a condition
that must be TRUE in order to permit or allow a particular operation to take place.
1. All options must be configured.
• All optional features must be selected or configure before they can be turned on. By default, if an option
is not selected, its function will be turned off.
2. Recovery Mode:
• The recovery mode feature is automatically turned on when the correct bag open type is selected.
The bag open must include a bag opened sensor installed on the funnel. The recovery feature can
be turned off by stetting the Bag Open and Bag Feed Retries to 0.
3. Ready to Cycle Permissive - All of the following conditions must be true before the machine will cycle:
• The Master Control Relay or MCR must be energized for 3 seconds. The MCR is energized when
the Green Pushbutton is illuminated.
• The Bagger cannot be faulted.
• Printer not in cycle (if equipped)
• Model Selection Test is not active.
• Batch Counter NOT done.
• All Bagger motions must be in their home positions as indicated by Position Sensor Feedback.
Pressure Bar Opened.
Seal Bar Retracted.
Vacuum Cylinder is retracted (if equipped)
If the Batch Counter function is on and the counter has reached its terminal count, then the counter must be
reset before the bagger can cycle again.
4. Complete Power Up Sequence - Machine must be connected to 120V power source and have an ade-
quate supply of clean, dry compressed air.
• Make sure the 120V Power Entry Module Switch is in the ON position.
• Release the E-Stop Button.
• Press the Green Power Button. The green light should illuminate and energized the MCR.
• The HMI will automatically start up when Power Entry Module Switch is turned ON.
5. Complete Power Down Sequence - The bagger must be properly power down in the correct sequence.
• Press the E-Stop Button to cut power to 24V DC power supply.
• From the Main Menu screen, press and hold the “Shutdown HMI” button for 3 seconds.
• ALLOW THE HMI/PC TO POWER DOWN COMPLETELY BEFORE CONTINUING TO NEXT
STEP. The HMI program is shutdown and Windows also need to shutdown. When completed, the
HMI screen will be black.
• Switch Power Entry Module Switch to OFF. The machine is now electrically shut down.
