Pregis SHARP MAX 1143 - Fault and Alert Management; Printer and Barcode Faults

MAX™ Operator Manual
©
Original Printed In English
SECTION 6 - FAULT & ALERT MANAGE-
6-1
Printer Offline Printer Option is turned on, but the
printer is faulted or offline
Go to Printer HMI Screen for de-
tailed information.
Barcode Fault Consecutive Bad Read Counter =
Barcode Fault Setting.
There is a problem with the Barcode
Scanner. The taught label is not the
same as the printed label or the
print quality of the label is poor and
cannot be read.
Master Control Relay Failed to
Open
Master Control Relay contact is
welded in the closed position after
the E-Stop button was pressed.
Master Control Relay should be in-
spected and/or replaced by a quali-
fied service technician.
Light Curtain Violation Safety Light Curtain was broken
while the bagger was in cycle.
Operators must wait until the bagger
cycle is completed before loading
parts.
Datamax Ribbon Fault Broken or missing printer ribbon on
printer. The Ribbon Motion Sensor
did not register any rotation of the
Rewind Roll during a print cycle.
Replace or repair ribbon.
Model Select R1 Missing The electronic circuit for model de-
tection did not find the R1 resistor in
the circuit or the circuit is open.
Power down the system and power
back up. Contact Sharp Packaging
Service Department.
Model Selection Failed The model selection cycle did not
function on power-up. The bagger
does not know what model is select-
ed.
Power down the system and power
back up. Contact Sharp Packaging
Service Department.
Excessive Parts Counted The Actual Number of parts loaded
into the open bag exceeded the Tar-
get Count.
The Filling Device is delivering parts
after the “Ready for Filler” switched
off, or the filling device delivered
multiple parts in a single charge and
those parts were counted by the
counting device, i.e. Light Curtain,
Photo eye, etc.
Vacuum Cylinder Failed to Extend The commanded motion did not
complete before the fault time ex-
pired.
See Cylinder Motion Fault.
Vacuum Cylinder Failed to Retract The commanded motion did not
complete before the fault timer ex-
pired.
See Cylinder Motion Fault.
FAULT
CAUSE SOLUTION
