Pregis SHARP MAX 1143 - Cylinder and Funnel Faults; Pressure Bar Faults

MAX™ Operator Manual
©
Original Printed In English
SECTION 6 - FAULT & ALERT MANAGE-
6-2
Vacuum Cylinder Sensor Conflict The cylinder position sensors are
providing conflicting position status.
See Sensor Conflict Fault.
Master Control Relay is Off E-Stop Button was pressed or E-
Stop is released but the green Pow-
er Button has not been pressed.
Release the E-Stop and press the
green Power Button.
Funnel Door Did Not Open The commanded motion did not
complete before the fault time ex-
pired.
See Cylinder Motion Fault.
Funnel Door Did Not Close The commanded motion did not
complete before the fault time ex-
pired.
See Cylinder Motion Fault.
Funnel Open/Close Conflict The cylinder position sensors are
providing conflicting position status.
See Sensor Conflict Fault.
Funnel Door Did Not Lower The commanded motion did not
complete before the fault time ex-
pired.
See Cylinder Motion Fault.
Funnel Door Did Not Raise The commanded motion did not
complete before the fault time ex-
pired.
See Cylinder Motion Fault.
Funnel Raise/Lower Sensor Conflict The cylinder position sensors are
providing conflicting position status.
See Sensor Conflict Fault.
Pressure Bar Failed to Open The commanded motion did not
complete before the fault time ex-
pired.
See Cylinder Motion Fault.
Pressure Bar Failed to Close The commanded motion did not
complete before the fault time ex-
pired.
See Cylinder Motion Fault.
Pressure Bar Sensor Conflict The commanded motion did not
complete before the fault time ex-
pired.
See Sensor Conflict Fault.
FAULT
CAUSE SOLUTION
