MAX™ Operator Manual
©
Original Printed In English
SECTION 6 - FAULT & ALERT MANAGE-
6-3
Pressure Bar Obstruction The Pressure Bar attempted to
close, but was blocked by an ob-
struction.
This is usually a part that did not
drop past the Pressure Bar. In-
crease the Filler Drop Timer setting.
Seal Bar Failed To Close The commanded motion did not
complete before the fault time ex-
pired.
See Cylinder Motion Fault.
Accumulating Funnel Did Not Open The commanded motion did not
complete before the fault time ex-
pired.
See Cylinder Motion Fault.
Accumulating Funnel Did Not Close The commanded motion did not
complete before the fault time ex-
pired.
See Cylinder Motion Fault.
Accumulating Funnel Open/Close
Sensor Conflict.
The cylinder position sensors are
providing conflicting position status.
See Sensor Conflict Fault.
Reverse Fault The Bag Edge Photo-Eye did not
detect the trailing edge of the film as
the web was backing up.
Check that the Photo-Eye is not
falsely sensing the Funnel Door. It
should only turn on when it sees the
film in front of it. It should turn off
just as the trailing edge of the film
unblocks the eye. Clean the Photo-
Eye lens with a soft cloth.
No Bag Covering The Eye There is no film in the machine or
the film is not being detected by the
Bag Edge Photo-Eye.
Press the Job Button once and the
bagger will jog the web for 10 sec-
onds until the Photo-Eye is covered
by film.
Seal Bar Over Temp. The actual Seal Bar temperature is
10 or more degrees below the Set
Point.
If the temperature Set Point was just
lowered, wait for Seal Bar Tempera-
ture to cool down. If the Over Temp.
Fault occurred when no change was
made to the Set Point, there any be
a failure in the Temperature Control
System. Press the E-Stop button if
the temperature continues to rise. A
qualified service technician must
troubleshoot the circuits.
FAULT
CAUSE SOLUTION
