MAX™ Operator Manual
©
Original Printed In English
SECTION 6 - FAULT & ALERT MANAGE-
6-4
Seal Bar Under Temp. The actual Seal Bar temperature is
more than 10 degrees below the Set
Point.
If the temperature Set Point was just
raised, wait for Seal Bar Tempera-
ture to heat up. If the Under Temp.
Fault occurred when no change was
made to the Set Point, there any be
a failure in the Temperature Control
System. Press the E-Stop button if
the temperature continues to fall. A
qualified service technician must
troubleshoot the circuits.
Thermocouple Failed - Open Circuit The Seal Bar actual temperature
display reads 32 degrees. The Ther-
mocouple circuit is open and is not
being read by the Thermocouple/
Voltage Transducer or the PLC Ana-
log input.
A qualified service person should
test the Thermocouple and its asso-
ciated circuits.
Dancer at Upper Limit The Unwind Dancer made the Up-
per Limit Switch during the Film
Feed.
The Unwind Speed Setting is too
low for the Film Feed Speed Setting.
Lower the Film Speed Setting or
increase the Unwind Speed.
Out Of Bags The bagger detected that the web is
broken or the bagger is out of bags.
Splice the broken web or replace
the empty roll/box.
Stepper Drive Faulted The Film Stepper Drive is reporting
a fault condition.
Reset the fault. If it does not clear,
power down the bagger for 2
minutes and power back up. If fault
does not clear, a qualified service
person must diagnose the problem.
Opened Bag Was Removed A bag was opened and verified as
open by the Bag Open Sensor. The
opened bag was physically removed
or came off the Bag Opened Sensor
before the Filler could finish deliver-
ing its product.
Check that the Funnel door is pin-
ning the opened bag to the Pressure
Bar. Verify that the bag is properly
supported by the Load Shelf as it is
being filled. It may be that as the
bag is being filled, it shifts or slips
off the shelf and pulls the bag away
from the Funnel.
Bag Failed To Open The Bag Opened Sensor failed to
make as the Funnel Door was at-
tempting to open the bag.
This fault is usually the result of a
bag quality problem or a problem
with the Funnel Door/Pressure Bar
Pass Through Adjustment. Also
check that the Sensor operates cor-
rectly.
FAULT
CAUSE SOLUTION
