MAX™ Operator Manual
©
Original Printed In English
SECTION 4 - HMI SCREENS
JOB DETAILS SCREEN - CONTINUED
Bag Length - This refers to the usable area inside the bag. This is measured from the bottom of the bag to the
seal. The typical setting is .5 to 1.5 inches less than the measured overall bag length.
Skirt Length - The distance from the bottom of the bag to the start of the seal.
Seal Dwell - The amount of time the heated seal bar will remain in contact with the film. High quality seals are
accomplished through proper seal time settings. These settings will vary with the film gauge and material.
HP Air Dwell - The amount of time the HP Air Blast remains on. The HP Air Blast is used to begin to open the
bag and is then taken over by the LP Air to hold the bag open during loading.
Seal Temp - The set temperature of the seal bar when sealing as bag.
Comments - These are comments that can be used to provide more information about the job.
Feed Delay - Adjusts the delay (in seconds) that occurs before the web feeds forward to present the next bag.
Feed Speed - Adjusts the forward web speed in inches per second.
Close P-Bar Delay - Adjusts the delay (in seconds) that occurs prior to closing the pressure bar.
Open P-Bar Delay - Adjusts the delay (in seconds) that occurs prior to opening the pressure bar.
Obstruction Sensitivity Delay - Adjusts delay (in seconds) of the timer that begins when the pressure bar is fired
to closed. This is a factory setting and should only be adjusted by a qualified service technician.
Reverse Speed - Adjusts the reverse web speed in inches per second.
Auto Dwell - Time, in seconds, that the bagger will pause between cycles when in Auto Mode and Filler Mode
OFF. This time delay is typically allotted to allow an operator to hand load product into the bag, i.e. a self-pace
setting.
LP Air Timeout - Low Pressure Air or LP Air is used to help keep the bag opened or inflated once it is first
opened by High Pressure Air (HP Air). LP Air Timeout operates as follows:
1. LP Air Timeout setting is between 0.1-999.8 seconds: LP Air will turn off after this time has expired.
2. LP Air Timeout is set to 999.9 seconds: LP Air will not turn OFF.
3. LP Air timeout is set to 0.0: LP Air will never turn ON.
4-6
