Pro-face ST Series - Page 23

ST Series User’s Manual
1-6
ST403-AG41-24V
RUN Mode
Bar-Code Reader*
1
(Limited to tested models)
RS422 Cable*
2
CA3-CBL422/5M-01
ST Unit
F1
F1
F2
F2
F3
F3
F4
F4
F5
F5
F6
F6
Tool Connector
X Port
Y Port
LAN Cable(RJ45)
(Conventional Products)
Host Controller
PLC etc,
Mitsubishi PLC FX Series
connection Cable
CA3-CBLFX/1M-01
CA3-CBLFX/5M-01
Transfer Cable
GPW-CB02
GPW-CB03
RS232C Cable*
2
CA3-CBL232/5M-01
Concentrator (Hub)
(Conventional Products)
PC
(Commercial Products)
General-purpose
Computer of
PLC series
or PLC etc

Pro-Server with
Pro-Studio

Mitsubishi
GPP Function
Software*
4
Mitsubishi PLC
A, QnA FX Series
2-Port AdaptorⅡ
GP070-MD11*
5
9pin <-> 25pin
Conversion Adaptor(RS232C)*
6
(commercial type)
Major Network
When using the Internal 2-Port feature*
3
Mitsubishi A Connection Cable
CA3-CBLA-01
Omron SYSMAC Cable
CA3-CBLSYS-01

Mitsubishi Q Connection Cable
CA3-CBLQ-01

Mitsubishi Q Link Cable
CA3-CBLLINKMQ-01
RS422 Cable
(User-created)*
5
