Prodys ProntoNet LC - Technical Specifications; VII.1 Audio Interfaces

ProntoNetLC User Manual 147
Technical Specifications
VII.1 Audio Interfaces
Stereo Audio Inputs:
 Balanced Analog inputs:
Maximum input level: +22 dBu
37
.
Input Impedance: 20 Kohm.
 Digital inputs:
AES/EBU format: EIAJ CP-340 tipo I/IEC-958 Pro
Rate Converter: 1:3 to3:1.
Stereo Audio Outputs:
 Balanced Analog Outputs:
Maximum output level: +22 dBu
57
.
Output Impedance: 50 ohm.
 Digital Outputs:
AES/EBU format: EIAJ CP-340 tipo I/IEC-958 Pro
Rate Converter: 1:3 to 3:1.
Audio properties
*
:
THD+N<0.0035%
S/N > 94 dB typical.
Crosstalk > 94 dB.
Phase Difference < 0.3º.
Quantification: 24 bits.
*
With a tone of +22 dBu, Fs=48 Khz, 24 bits
37
This is the default factory configuration. It can be configured to +4,+18 or +22dBu.
Appendix A
