ProntoNetLC User Manual
17
II.3.6 Microswitches
There are 8 microswitches on the back panel which are reserved for special
functions. Before turning on the unit the user must check that they are
configured according to the following diagram, which is the standard start-up
configuration:
Switch number 7 will restore the default factory configuration. The IP address is
changed to 192.168.100.100 and the netmask to 255.255.255.0.
