ProntoNetLC User Manual
25
L : > > > > > > > 4 1
R : > > > > > > > 4 1
III.2.2 The INF key
This key allows the user a simple and quick way to display detailed information
on the status and configuration of the ProntoNetLC. Given that the screen is not
able to display all the information at once, you can cycle through the different
information screens by repeatedly pressing the INF button, or by using the left
and right directional arrows. These screens are:
1. Audio input VU meters.
2. Audio output VU meters.
3. Decoding algorithm.
4. Encoding algorithm.
5. IP configuration parameters.
6. General configuration: NET type (IP), audio input, etc.
7. GPIO status and Serial Port bit rate.
III.2.2.1. Screen 1: Audio input VU meters
The audio input levels are represented on-screen horizontally over 18 characters.
Each character represents 3dB. All characters showing will represent 0 dBFs.
When only one character is showing it therefore represents a value between –96
and –56 dBFs. The dBFs value is indicated on the right of the LCD screen. The
input is indicated by a < symbol following the L and R characters.
III.2.2.2. Screen 2: Audio output VU meters
The audio input levels are represented on-screen horizontally over 18 characters.
Each character represents 3dB. All characters showing will represent 0 dBFs.
When only one character is showing it therefore represents a value between –96
and –56 dBFs. The dBFs value is indicated on the right of the LCD screen. The
output is indicated by a > symbol following the L and R characters.
L : > > > > > > > 4 1
R : > > > > > > 4 4
