ProntoNetLC User Manual
31
S E T E N C O D E R 1 > >
{ A U T } P C M G 7 1 1 G 7 2 2
< < S E T E N C O D E R 1
M P L 2 M P L 3
IV.4.1 Configuration of Encoder 1
The configuration of Encoder 1 is done in steps, starting with the selection of an
algorithm and following on with the different parameters that relate to that
particular algorithm. The ProntoNetLC menu will always only display the options
and parameters that are relevant to each algorithm’s configuration. In the
following description these different parameters are outlined for each algorithm.
Additionally there are certain restrictions associated with the communication
interface selected. For example, uncompressed audio can only be selected when
the NET is set to IP. In the following description these restrictions are outlined
for each algorithm.
Selecting the algorithm
For Encoder 1 the following options are available:
AUT : Automatic Mode. This means that the Encoder adopts the same mode
as the Decoder. (This is equivalent to the automatic dependent mode of the
Pronto 3).
PCM : Line audio without compression.
G711 : Compatible with the telephone standard
G722 : Low delay Algorithm appropriate for high quality voice.
MPL2 : MPEG 1,2 Layer II.
MPL3 : MPEG 1,2 Layer III.
Note: Other compression modes such us MPEG AAC LC, LD and HE can
be provided under license.
NOTICE – RESTRICTIONS ON THE DIFFERENT NETWORKS
PCM is only available if NET = IP.
G711 is only available if NET = IP.
Next follows the parameters and restrictions associated with each algorithm.
