Prodys ProntoNet LC - For Line 2 the Options Are Laid out in the same Way; IV.6.2.3. Configuration of the X21 Port; IV.6.2.4. Configuration of the RS232 Ports

ProntoNetLC User Manual 48
S E T R S 2 3 2 P O R T
{ P O R T A } P O R T B
S E T R S 2 3 2 P O R T A > >
{ 3 0 0 } 1 2 0 0 2 4 0 0 4 8 0 0
S E T X 2 1 P O R T
{ 6 4 } 1 2 8 1 9 2 2 5 6 3 8 4 5 7 6
L I N E 1 S P I D N U M B E R
-
L I N E 1 A N S W E R M O D E
M A N U A L { A U T O }
L I N E 1 E X T . L O O P
O N { O F F }
 SPID:
 ANS:
 LOOP:
For Line 2 the options are laid out in the same way.
IV.6.2.3. Configuration of the X21 port
18
The configuration of the X21 port consists of selecting the operational speed.
The options available are: 64, 128, 192, 256, 384 and 576Kbps.
IV.6.2.4. Configuration of the RS232 ports
The RS232 ports are there for the transmission/reception of auxiliary data. Here
the operational speed is set for each one.
18
This interface is available under license.
