ProntoNetLC User Manual
50
S E T P L L
{ I P } X 2 1
F A N M E N U
{ O F F } A U T
A U X . D A T A M E N U
{ R S 2 3 2 } G P I O
R S 2 3 2 D A T A M E N U
{ O F F } D E C 1 D E C 2 B O T H
IV.6.3.2. PLL
This is a special option that allows you to select the PLL reference clock when
NET = IP.
IV.6.3.3. FAN
To enable/disable the fan.
In AUT mode fan is temperature controlled and will switch itself on and off
automatically as required. The fan will start working when the temperature goes
up above 34ºC, and stop working when it goes down below 32ºC
20
.
IV.6.3.4. AUXDATA
This option allows the user to configure if the decoder will be able to receive
ancillary data or not.
It is possible to enable independently the RS232 port and the GPIO port.
There are two decoders DEC1 and DEC 2 in case the ProntoNetLC works as
dual codec so, it is possible to have auxiliary data on both or either of them.
20
Before version 5.2.1, the fan stopped working when the temperature went down below 34ºC.
