ProntoNetLC User Manual
43
C O N F A E S / E B U S Y N C
{ A U D I O } E X T
C O N F P O R T S M E N U
{ L A N } X 2 1 R S 2 3 2
AES/EBU
If we select AES/EBU next we will see a screen where it will be possible to select
the sync type – internal (with the digital audio input) or external (coming from
another device connected to the AES/EBU connector).
AES/EBU TRANSPARENT
The AES/EBU TRANSP is a special transmission mode for PCM 24 bits digital
audio without any processing at all. This mode allows the user to transmit “NON-
PCM audio” or data between devices that use AES3 digital audio interface, for
example Dolby E systems.
This mode is only available when ProntoNetLC works as an IP
codec (NET = IP).
When this option is selected, the Encoder options are
disabled.
IV.6.1.2. AUDIO LEVELS
From here, the audio input/output levels can be configured for the right and left
channels. The defined levels will be applied before the encoding process for the
input, and after the decoding process for the output.
IV.6.2 CONF-PORTS
This is for configuring the communication ports of the unit.
LAN: for configuring the LAN port.
X21: for configuring the X21 port
16
.
RS232: for configuring the speed of each of the two RS232 ports.
16
This interface is available as option.
