Prodys ProntoNet LC - III.2.2.5. Screen 5: LAN Port Configuration Parameters; III.2.2.6. Screen 6: General Configuration; III.2.2.7. Screen 7: GPIO and Serial Port Bit Rate

ProntoNetLC User Manual 27
A D D R : 1 9 2 . 1 6 8 . 1 0 0 . 1 0 0
M A S K : 2 5 5 . 2 5 5 . 2 5 5 . 0 0 0
C O D E C I P
A U D I O I N : A N A L O G
C O D E C I P
A U D I O I N : D I G - E X T
G P I : 0 0 0 0 0 0 0 P A : 9 6 0 0
G P O : 1 0 1 0 0 0 0 P B : 9 6 0 0
If the Encoder is configured to automatic mode or if the Decoder is not
synchronised you will see the following:
III.2.2.5. Screen 5: LAN port configuration parameters
Here we see the IP address and mask.
III.2.2.6. Screen 6: General configuration
This shows the NET type and the audio input selected. Here are two such
examples:
a) Analog audio input:
b) Digital audio input with external sync:
III.2.2.7. Screen 7: GPIO and Serial Port bit rate
This represents the GPIO status:
E 1 : A U T O
E 2 : N O T A V A I L A B L E
