ProntoNetLC User Manual
30
N E T S E L E C T I O N
{ I P } X 2 1
S E T E N C O D I N G M O D E
{ E N C O D E R 1 }
INF: From here you can obtain information on the software version and
various configuration parameters of the communication port.
IV.3 NET: Selecting a communications port.
The ProntoNetLC has one communication port as default: IP. X21 interface
can be provided under license.
The NET option is only available if the lines are not already connected. If they
are busy, the display will show the following text:
Each NET type selection will of course have their own set of configuration
parameters, as will be seen next.
IV.4 ENC: Encoder algorithm selection menu
From this option we can choose the audio Encoder algorithms. Note that the
ProntoNetLC can operate as a DUAL codec
7
. In this case, it is possible to have
two simultaneous communications that are totally independent and so it is
possible to use the second Encoder but not to configure it, because it will be
fixed to G722.
If we select ENC from the main menu the following is displayed:
ENCODER 2 is only available if the unit is configured as a DUAL codec, but
it is fixed to G722.
7
DUAL codec: ProntoNetLC is able to operate as a DUAL codec over IP (when configured in
‘DOUBLE’ mode).
N O T A V A I L A B L E W I T H
L I N E C O N N E C T E D
