ProntoNetLC User Manual
71
V.1.1.5. GPIO Port
From this option the inputs and outputs of the GPIO port are configured.
INPUTS
Transparent Under this configuration, the state of the input will be present in
its homologous output in the ProntoNetLC connected on the other
end.
Connect From Book When this input is activated, the ProntoNetLC will proceed
automatically to connect the line 1 or line 2 (as configured). The
user can select which entry of the book will be used for this
purpose.
Disconnect Line 1 When this input is activated, the ProntoNetLC will proceed
automatically to disconnect the line 1.
Disconnect Line 2 When this input is activated, the ProntoNetLC will proceed
automatically to disconnect the line 2.
Mute Left When this input is activated, the left audio output will be muted.
Mute Right When this input is activated, the right audio output will be muted.
Acknowledge alarms When this input is activated, the alarms will be acknowledged.
Answer Line1
24
Line 1 will be picked up when receiving a call.
Answer Line2
23
Line 2 will be picked up when receiving a call.
The inputs are activated by grounding
Transparent configuration only works with audio algorithms that support
ancillary data and have been previously activated.
24
From version 5.2.1 onwards.
