ProntoNetLC User Manual
99
Voltage Out of Range 12 v Main: The voltage from the main power supply
(AC/DC) is out of range.
Voltage Out of Range 12 v Backup: The voltage from the backup power
supply is out of range.
Voltage Out of Range 3.3 v System: The voltage from the 3.3 DC/DC
converter is out of range.
Voltage Out of Range 5 v System: The voltage from the 5 DC/DC
converter is out of range.
Temperature Out of Range: The temperature is out of range
29
.
Fan Failure: The fun is activated if the internal temperature is over 34º. The
Fan Failure alarm will be activated if the fun doesn’t work when the
temperature is over this threshold.
LAN NOT Present: Not physical level detected in the LAN port.
LAN Traffic: The LAN traffic is higher than the 90% of the capacity of the
network.
X21 Line Not Present: Not physical level detected in the X21 port.
ISDN NOT Present: Not physical level detected in the ISDN port.
No Audio input level detected: No audio is present on the input. A
threshold and a time period can be defined to activate the alarm.
Decoder 1/2 Framed Lost: The Line is connected but the decoder is not
framed, but it was framed before. The alarm will be activated also if the unit
is turned off. In this case, the alarm will indicate the date and time when the
decoder lost the synchronization, that is, when the unit was turned off. The
alarm will be activated until the unit is framed once the line is connected
again. If the connection is not possible, the alarm will be marked as finished.
Decoder 1/2 Not Framed: The Line is connected but the decoder is not
framed. This new alarm doesn’t require that the decoder was framed
previously. For this reason, it is necessary to specify a window time to decide
when the alarm will be activated once that the NOT FRAMED condition has
been detected.
Otherwise, the alarm would come up as soon as the connection is
established, given that the Decoder needs some time to detect the incoming
compression mode.
29
The temperature is above 50ºC.
