Promise Technology Pegasus3 R4 User Manual

87
Managing the Pegasus3Pegasus3 Product Manual
PDM
Predictive Data Migration (PDM) is the migration of data from the suspect disk drive to a spare drive,
similar to rebuilding a disk array. But unlike rebuilding, PDM automatically copies your data to a spare
drive before the drive fails and your logical drive goes Critical.
PDM can be triggered automatically by Media Patrol. Also see ”Running PDM on a Logical Drive” on
page 142.
Making PDM Settings
To make PDM settings:
1. Click on the Background Activities icon.
2. Click the Settings button.
3. Make the following settings are required:
• Click the PDM Rate dropdown menu and choose a rate:
• Low – Fewer system resources to PDM, more to data read/write operations.
• Medium – Balances system resources between PDM and data read/write operations.
• High – More system resources to PDM, fewer to data read/write operations.
• Highlightthecurrentvaluesintheblockthresholdeldsandinputnewvalues.
Reassigned block threshold range is 1 to 512 blocks. Error block threshold range is 1 to
2048 blocks.
4. Click the Conrmbutton.
5. Click the X icon to close the background activities panel.
PDM

Promise Technology Pegasus3 R4 Specifications

General

Internal	No
Chassis type	Tower
Cooling type	Active
Device class	Small & Medium Business
Fan diameter	92 mm
Certification	CB, UL, cUL, TUV , BSMI, SPRING, BIS FCC, CE-EMC, VCCI, BSMI, RCM KCC
Product color	Black
LED indicators	Yes
Number of fans	1 fan(s)
Airflow (imperial)	70 cfm
Management platform	Pegasus Utility
Cable lock slot type	Kensington
RAID levels	0, 1, 1E, 5, 6, 10
Data transfer rate	40 Gbit/s
Storage drive size	3.5 \
Storage drive capacity	4000 GB
Storage drive interface	Serial ATA
Installed storage drive type	HDD
Supported storage drive types	HDD & SSD
Total installed storage capacity	16 TB
Maximum supported storage capacity	- TB
Number of storage drives installed	4
AC input voltage	100-230 V
AC input frequency	50 - 60 Hz
Number of power supply units	1
Power supply unit (PSU) capacity	250 W
Thunderbolt version	3
Thunderbolt ports quantity	2
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	5 - 35 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	10 - 95 %
Cables included	AC, Thunderbolt

Weight and Dimensions

Depth	188 mm
Width	248 mm
Height	195 mm
Weight	6800 g
